RL78/G16微控制器Renesas瑞薩
發布時間：2024-04-19 09:30:59 瀏覽：567
RL78/G16微控制器是一款由Renesas推出的通用微控制器，具備高達16MHz的工作頻率的電容式觸摸通道。這款微型小引腳通用微控制器特別適合家用電器和高溫環境操作要求。它配備了電容式傳感器單元，并提供豐富的產品線，包括10引腳產品在內，是瑞薩電子最小的引腳封裝之一。此外，該微控制器還配備了功能安全的硬件，有助于用戶通過家用電器安全標準IEC/UL60730認證。由于內置了高精度(±1.0%)的高速片上振蕩器、數據閃存、豐富的串行接口和比較器，它非常適合要求節省空間的應用場合。
- CPU核心：搭載RL78內核，最高主頻可達16MHz。
- 工作電壓：范圍從2.4V到5.5V，適應不同電路需求。
- **引腳封裝**：提供10至32引腳的產品線，適用于各種尺寸的設計。
- 存儲：具有16KB或32KB的程序閃存、2KB SRAM和1KB數據閃存，滿足數據處理需求。
- 工作溫度：可在不超過125°C的環境下正常工作。
- 電容式感應單元：增強型電容式感應單元(CTSUb)可用于觸摸應用。
- 定時器：提供8路16位定時器、1路看門狗定時器、1路12位間隔定時器和1路實時時鐘。
- PWM輸出：支持7路PWM輸出，可用于精確控制電平。
- 模擬功能：包含11路8/10位A/D轉換器，適用于模擬信號處理。
- 片上振蕩器：高速振蕩器可達最高16MHz，低速振蕩器頻率為15kHz。
- 安全功能：具備A/D測試、CRC計算器、RAM奇偶校驗錯誤檢測、頻率檢測、無效存儲器訪問檢測等功能，提升系統穩定性。
- 其他功能：支持通電重置、低電壓檢測、片上調試功能。
- 封裝：提供SSOP、LQFP、QFN等多種封裝形式，方便集成至不同的電路板設計中。
RL78/G16微控制器提供多種便利的開發環境，如評估板(Fast Prototyping
Board)可通過USB線進行編寫和調試程序，智能配置器(Smart
Configurator)通過GUI簡化設計，電容式觸摸評估系統縮短觸摸界面開發周期。此外，該微控制器與現有的RL78系列兼容，可無縫切換，適用于家電、消費類電子產品和工業設備等廣泛用途。
產品型號：
| Product ID | 程序存儲器 （KB） | 內存 （KB） | 溫度范圍 | 電源電壓 （V） | 工作頻率（最大值） （MHz） | 產品尺寸 （mm） |
| R5F1211AASP#10 | 16 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 4 x 4 x 1.45 |
| R5F1211CASP#30 | 32 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 4 x 4 x 1.45 |
| R5F1211CGSP#10 | 32 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 4 x 4 x 1.45 |
| R5F1211AASP#50 | 16 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 4 x 4 x 1.45 |
| R5F1211CGSP#30 | 32 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 4 x 4 x 1.45 |
| R5F1211CGSP#50 | 32 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 4 x 4 x 1.45 |
| R5F1211AGSP#30 | 16 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 4 x 4 x 1.45 |
| R5F1211AGSP#50 | 16 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 4 x 4 x 1.45 |
| R5F1211CMSP#30 | 32 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 4 x 4 x 1.45 |
| R5F1211AMSP#10 | 16 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 4 x 4 x 1.45 |
| R5F1211CMSP#50 | 32 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 4 x 4 x 1.45 |
| R5F1211AMSP#50 | 16 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 4 x 4 x 1.45 |
| R5F1211CASP#10 | 32 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 4 x 4 x 1.45 |
| R5F1214AANA#20 | 16 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 1 x 3 x 3 |
| R5F1214AGSP#50 | 16 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 5 x 4 x 1.725 |
| R5F1214CMNA#40 | 32 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 1 x 3 x 3 |
| R5F1214AANA#00 | 16 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 1 x 3 x 3 |
| R5F1214CASP#10 | 32 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 5 x 4 x 1.725 |
| R5F1214AGSP#30 | 16 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 5 x 4 x 1.725 |
| R5F1214CMNA#20 | 32 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 1 x 3 x 3 |
| R5F1214CANA#40 | 32 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 1 x 3 x 3 |
| R5F1214AGSP#10 | 16 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 5 x 4 x 1.725 |
| R5F1214AGNA#00 | 16 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 1 x 3 x 3 |
| R5F1214CGSP#50 | 32 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 5 x 4 x 1.725 |
| R5F1214CANA#20 | 32 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 1 x 3 x 3 |
| R5F1214CMNA#00 | 32 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 1 x 3 x 3 |
| R5F1214CASP#30 | 32 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 5 x 4 x 1.725 |
| R5F1214CMSP#10 | 32 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 5 x 4 x 1.725 |
| R5F1214AMNA#00 | 16 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 1 x 3 x 3 |
| R5F1214CASP#50 | 32 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 5 x 4 x 1.725 |
| R5F1214AGNA#40 | 16 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 1 x 3 x 3 |
| R5F1214AANA#40 | 16 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 1 x 3 x 3 |
| R5F1214CMSP#30 | 32 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 5 x 4 x 1.725 |
| R5F1214CGNA#00 | 32 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 1 x 3 x 3 |
| R5F1214AASP#10 | 16 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 5 x 4 x 1.725 |
| R5F1214CMSP#50 | 32 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 5 x 4 x 1.725 |
| R5F1214AMNA#40 | 16 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 1 x 3 x 3 |
| R5F1214CGNA#20 | 32 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 1 x 3 x 3 |
| R5F1214AASP#30 | 16 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 5 x 4 x 1.725 |
| R5F1214AMSP#10 | 16 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 5 x 4 x 1.725 |
| R5F1214CGNA#40 | 32 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 1 x 3 x 3 |
| R5F1214AASP#50 | 16 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 5 x 4 x 1.725 |
| R5F1214AMSP#30 | 16 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 5 x 4 x 1.725 |
| R5F1214AMSP#50 | 16 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 5 x 4 x 1.725 |
| R5F1214AGNA#20 | 16 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 1 x 3 x 3 |
| R5F1214CANA#00 | 32 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 1 x 3 x 3 |
| R5F1214CGSP#30 | 32 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 5 x 4 x 1.725 |
| R5F1214CGSP#10 | 32 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 5 x 4 x 1.725 |
| R5F1216AMSP#50 | 16 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 6 x 4 x 1.45 |
| R5F1216CASP#50 | 32 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 6 x 4 x 1.45 |
| R5F1216CGSP#30 | 32 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 6 x 4 x 1.45 |
| R5F1216CGSP#50 | 32 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 6 x 4 x 1.45 |
| R5F1216CMSP#30 | 32 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 6 x 4 x 1.45 |
| R5F1216CMSP#50 | 32 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 6 x 4 x 1.45 |
| R5F1216AASP#50 | 16 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 6 x 4 x 1.45 |
| R5F1216AGSP#30 | 16 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 6 x 4 x 1.45 |
| R5F1216AGSP#50 | 16 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 6 x 4 x 1.45 |
| R5F1216AMSP#30 | 16 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 6 x 4 x 1.45 |
| R5F1217CANA#00 | 32 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 4 x 4 x 0.8 |
| R5F1217CANA#20 | 32 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 4 x 4 x 0.8 |
| R5F1217AANA#00 | 16 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 4 x 4 x 0.8 |
| R5F1217CANA#40 | 32 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 4 x 4 x 0.8 |
| R5F1217AANA#20 | 16 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 4 x 4 x 0.8 |
| R5F1217CGNA#00 | 32 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 4 x 4 x 0.8 |
| R5F1217CGNA#20 | 32 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 4 x 4 x 0.8 |
| R5F1217AGNA#00 | 16 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 4 x 4 x 0.8 |
| R5F1217CGNA#40 | 32 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 4 x 4 x 0.8 |
| R5F1217AGNA#20 | 16 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 4 x 4 x 0.8 |
| R5F1217CMNA#00 | 32 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 4 x 4 x 0.8 |
| R5F1217CMNA#20 | 32 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 4 x 4 x 0.8 |
| R5F1217AMNA#00 | 16 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 4 x 4 x 0.8 |
| R5F1217CMNA#40 | 32 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 4 x 4 x 0.8 |
| R5F1217AMNA#20 | 16 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 4 x 4 x 0.8 |
| R5F1217AMNA#40 | 16 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 4 x 4 x 0.8 |
| R5F121BCGFP#10 | 32 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 7 x 7 x 1.7 |
| R5F121BCMNA#40 | 32 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 5 x 5 x 0.8 |
| R5F121BAMFP#50 | 16 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 7 x 7 x 1.7 |
| R5F121BCGFP#30 | 32 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 7 x 7 x 1.7 |
| R5F121BAANA#20 | 16 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 5 x 5 x 0.8 |
| R5F121BAMNA#00 | 16 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 5 x 5 x 0.8 |
| R5F121BCGFP#50 | 32 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 7 x 7 x 1.7 |
| R5F121BAANA#40 | 16 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 5 x 5 x 0.8 |
| R5F121BAMNA#20 | 16 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 5 x 5 x 0.8 |
| R5F121BCGNA#00 | 32 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 5 x 5 x 0.8 |
| R5F121BAGFP#10 | 16 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 7 x 7 x 1.7 |
| R5F121BAMNA#40 | 16 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 5 x 5 x 0.8 |
| R5F121BCGNA#20 | 32 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 5 x 5 x 0.8 |
| R5F121BAGFP#30 | 16 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 7 x 7 x 1.7 |
| R5F121BCAFP#10 | 32 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 7 x 7 x 1.7 |
| R5F121BCGNA#40 | 32 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 5 x 5 x 0.8 |
| R5F121BAGFP#50 | 16 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 7 x 7 x 1.7 |
| R5F121BCMFP#10 | 32 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 7 x 7 x 1.7 |
| R5F121BAGNA#00 | 16 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 5 x 5 x 0.8 |
| R5F121BCAFP#50 | 32 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 7 x 7 x 1.7 |
| R5F121BCMFP#30 | 32 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 7 x 7 x 1.7 |
| R5F121BAGNA#20 | 16 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 5 x 5 x 0.8 |
| R5F121BCANA#00 | 32 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 5 x 5 x 0.8 |
| R5F121BCAFP#30 | 32 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 7 x 7 x 1.7 |
| R5F121BAAFP#10 | 16 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 7 x 7 x 1.7 |
| R5F121BCMFP#50 | 32 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 7 x 7 x 1.7 |
| R5F121BCANA#20 | 32 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 5 x 5 x 0.8 |
| R5F121BAAFP#30 | 16 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 7 x 7 x 1.7 |
| R5F121BCMNA#00 | 32 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 5 x 5 x 0.8 |
| R5F121BAMFP#10 | 16 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 7 x 7 x 1.7 |
| R5F121BCANA#40 | 32 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 5 x 5 x 0.8 |
| R5F121BAAFP#50 | 16 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 7 x 7 x 1.7 |
| R5F121BCMNA#20 | 32 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 5 x 5 x 0.8 |
| R5F121BAMFP#30 | 16 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 7 x 7 x 1.7 |
| R5F121BAANA#00 | 16 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 5 x 5 x 0.8 |
| R5F121BAGNA#40 | 16 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 5 x 5 x 0.8 |
| R5F1211AASP#30 | 16 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 4 x 4 x 1.45 |
| R5F1211AMSP#30 | 16 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 4 x 4 x 1.45 |
| R5F1211CMSP#10 | 32 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 4 x 4 x 1.45 |
| R5F1214AMNA#20 | 16 | 2 | -40 to 125°C | 2.4 - 5.5 | 16 | 1 x 3 x 3 |
| R5F1216AASP#30 | 16 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 6 x 4 x 1.45 |
| R5F1216CASP#30 | 32 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 6 x 4 x 1.45 |
| R5F1217AANA#40 | 16 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 4 x 4 x 0.8 |
| R5F1217AGNA#40 | 16 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 4 x 4 x 0.8 |
| R5F1211CASP#50 | 32 | 2 | -40 to 85°C | 2.4 - 5.5 | 16 | 4 x 4 x 1.45 |
| R5F1211AGSP#10 | 16 | 2 | -40 to 105°C | 2.4 - 5.5 | 16 | 4 x 4 x 1.45 |
